14 GAUGE TITANIUM WIRE STOCK FOR SALE
Yesheng's 14 gauge titanium wire is on sale, providing excellent strength, flexibility, and resistance to corrosion. Perfect for medical, aerospace, and industrial uses, this titanium flat wire guarantees dependable performance and lasting durability. Contact Yesheng for more custom titanium products tailed to your needs.
14 GAUGE TITANIUM WIRE SPECIFICATION• Grade 2 (UNS R50400 / 3.7035): Industrial pure titanium, with a titanium content of more than 99%, more corrosion-resistant than Gr5.
| Titanium Grade 2 | Ti | Fe | O | C | N | H |
| Min% | - | - | - | - | - | - |
| Max% | Bal | 0.3 | 0.25 | 0.08 | 0.03 | 0.015 |
TITANIUM GRADE 2 - Tensile Data
| Temperature (°F) | Ultimate Tensile (ksi) | Yield Strength at 0.2% Offset (ksi) | Elongation % |
| Room Temp | 70 | 50 | 28 |
| 212 | 56 | 37 | 31 |
| 392 | 41 | 28 | 37 |
| 572 | 33 | 18 | 43 |
| 752 | 27 | 13 | 38 |
| 842 | 26 | 11 | 34 |
• Grade 5 (UNS R56400 / 3.7165): The nominal composition of Gr5 is Ti-6al-4v, which is the most widely used titanium alloy. It has extremely strong mechanical properties and corrosion resistance. Often used in the aerospace and marine industries.
| Titanium Grade 5 | Ti | Al | V | Fe | O | C | N | H |
| Min% | - | 5.5 | 3.5 | - | - | - | - | - |
| Max% | Bal | 6.75 | 4.5 | 0.3 | 0.2 | 0.08 | 0.05 | 0.015 |
TITANIUM GRADE 5 - Tensile Data
| Temperature (°F) | Ultimate Tensile (ksi) | Yield Strength at 0.2% Offset (ksi) | Elongation % |
| Room Temp | 13S | 128 | 14 |
| 300 | 121 | 105 | 16 |
| 500 | 110 | 93 | 17 |
| 700 | 100 | 82 | 18 |
Titanium Grade 7 Specifications: ASTM - B265, B337, B338, B348, B363, B381, B861 and B862, EN 3.7235.
| Titanium Grade 7 | Ti | Fe | Pd | O | C | N | H |
| Min% | - | - | 0.12 | - | - | - | - |
| Max% | Bal | 0.3 | 0.25 | 0.25 | 0.08 | 0.03 | 0.015 |
TITANIUM GRADE 7 - Tensile Data
| Temperature （F） | Ultimate Tensile （ksi） | Yield Strength at 0.2% Offset （ksi） | Elongation % |
| Room Temp | 50 | 40 | 20 |
| 200 | 57 | 40 | 28 |
| 400 | 41 | 24 | 41 |
| 600 | 32 | 15 | 38 |
Custom 14 Gauge Titanium Wire
